Skytile 1200x300 30W IP44 4000K 3000lm TP(a) UGR <19 1-10
JC080117
- Meets TP(a) requirements, suitable for all applications
- UGR <19 as standard, designed to comply with BS EN 12464-1 lighting of workspace
- Ultra efficient 100LpcW
- DALI/1-10V and DSI Dimming versions available
- IP44 protection against dust and moisture
- Comes with non-dimmable flicker free driver as standard
- Suspension kits and surface mount boxes available
- Suitable for use with JCEM002 and JCEM002ST emergency remote packs
Country of Origin: Please Contact Customer Service
Product Information
Electrical
Class : II
Dimmable : 1-10V
Luminaire Circuit Wattage : 30
Voltage Rating : 220-240
General Information
IP Rating : IP44
Light Source Features : Neutral White
Luminaire Accessories : Skytile surface mount tray(JC71299) Suspension kit (JC71312)
Method of fix : sits in 15mm and 25mm ceiling grid system
Mounting : Recessed
Overall Dimensions : 295 x 1195 x 10.6 mm
Trade Name : Skytile
Warranty : 5 Year Warranty (inc 2 year on site)
Performance Data
Actual Lumen Output : 3000
Beam Angle ° : 90
CRI: Ra : 80
Correlated Color Temperature : 4000K
Lumens Per Circuit Watt : 100 LpcW
Thermals
Insulation Coverage : do not cover
Operating Temperature Range °C : -25 to +50
